CUI Devices SJ-3524-SMT-TR-PI In Stock Bulk sales (1 piece or more)
- Model Number
- SJ-3524-SMT-TR-PI
- Manufacturer
- CUI Devices
- Datasheet
- SJ-3524-SMT-TR-PI PDF
- Description
- CONN JACK STEREO 3.5MM SMD R/A
In Stock : 626
USD $1.02
Payments
Shipping
Product Details
- Manufacturer
- CUI Devices
- Series
- SJ
- Packaging
- Cut Tape
- Product Status
- Active
- Connector Type
- Phone Jack
- Gender
- Female
- Signal Lines
- Stereo (3 Conductor, TRS)
- Industry Recognized Mating Diameter
- 3.50mm (0.141", 1/8", Mini Plug) - Headphone
- Actual Diameter
- 0.142" (3.60mm)
- Number of Positions/Contacts
- 3 Conductors, 4 Contacts
- Internal Switch(s)
- Single Switch
- Mounting Type
- Surface Mount, Right Angle
- Termination
- Solder
- Shielding
- Unshielded
- Features
- Board Guide
- Insulation Color
- -
- Operating Temperature
- -25°C ~ 85°C
- Voltage - Rated
- 12VDC
- Current Rating (Amps)
- 1 A
- Mating Length/Depth
- 0.551" (14.00mm)
- Contact Material - Plating
- Silver
- Body Material
- -
- Body Color
- Pink
- Includes
- -
- Housing Material
- Polyamide (PA6T), Nylon 6T
- Contact Material
- Brass, Copper Alloy
- Cable Opening
- -
- Panel Hole Size
- -
- Thread Size
- -
- Base Product Number
- SJ-35
